Tech-LED is
the LED division of Marubeni America Corporation. We are pleased
to announce that Marubeni America acquired a 20% share of Epitex
Incorporated in March 2008. Our goal is to support your LED
requirements by offering more than 50 wavelengths from 360 to
1550 nm, including hard-to find, unique wavelengths, available
in surface-mount, thru-hole packages, multi-chip arrays and
chip form. Our recent introduction of high-power LEDs, surface
mount LEDs with lenses, and multi-wavelength LEDs has further
strengthened our already-extensive product line. Let Marubeni
help you find the best LED solutions whether your needs are
unusual optoelectronic performance or high volume cost-efficient
solutions. If you have any questions or comments, please contact
us.
Our supplier:
Epitex Incorporated
Marubeni America Corporation is a large share holder of
Epitex Incorporated. Epitex is the leader in infrared
LED technology with the highest power, widest variety
of wavelengths, packages and half-viewing angles in the
world. Epitex LEDs have been approved for numerous CCTV
light source, ITS,
security, biometrics,
night vision, medical,
photo-therapy,
machine
vision, infrared
wireless communication, and consumer electronics
applications. Epitex's extensive product lines include
LED die, molded LEDs in 3mm T1, 5mm T1 3/4, 7mm stem type
LEDs, surface mount LEDs, photodiodes, high power illuminators
and arrays, bi-color LEDs, UV LEDs, multi-wavelength LEDs
and point-source LEDs, and newly introduced surface-mount
power LEDs. The wavelengths range form ranging from 370
nm to 1550 nm and include hard-to find, application specific
wavelengths, such as 395, 418, 620, 735, 760, 810, 970,
1070, and 1450 nm. For molded LEDs are available in 3mm,
4mm, 5mm, 7mm and 10 mm types with a variety of LED chips
sizes such as 200, 300, 350, 400, 550 and 800 micron.
Epitex also offers custom LED and chip-on-board solutions.
If you have any questions or comments, please contact
us.
|
New Product -- SMT with Lens |
 |
Surface mount LEDs are now available with lens. The standard lens options are +/- 15, +/- 20, and +/- 28 degree half viewing angles.
We can offer SMT with lens in any standard IR and NIR wavelength you desire.
Please contact us for details.
|
New Product -- High Power Type Top LED with Lens (SMB and BL series)
We are pleased to offer 2 types of High Power Type Top LED with lens: the SMB series
and the BL series. The SMB has 1.0mm square chip mounted on copper heat sink in
a 5x5 mm package and molded with super beam lens of +/- 12 degree half view angle
(picture shown on the left). The BL also has 1.0mm square chip mounted on copper
heat sink in 7mm diameter round package and molded with super beam lens of +/- 7
degree half view angle. Standard wavelengths offered in SMB and BL lines include
470nm, 680nm, 760nm, 810nm, 850nm, and 940nm. Please check out the Superbeam LED page or
contact us for more information.
|
New Product –- U V High Power Type Top LED
Our new UV High Power Type Top LED consists of a 1 mm x 1mm InGaN die mounted on
a ceramic package with a copper heat sink and covered with silicon resin. It emits
at a peak wavelength of 395nm and has typical power output of 70mW at 200mA. It
is available with silicon lens, SMCC395-1100-02 (+/- 10 degree half view angle),
and without lens, SMCC395-1100 (+/- 60 degree half view angle). For more information,
please contact us.
|
New Product -- Flat Top Molded LED for Optic Fiber Cable (-31 package)
The newly introduced flat top molded LED -31 package is designed to work with optic
fiber cables. Its flat top lens and elevated chip location inside enable maximum
light input into cables. The -31 package is available at a very reasonable price
in all standard UV, IR and NIR wavelengths.
Please contact us for more information.
|
New Product -- Surface Mount Type LED
Illuminator (SMAL series)
Our high power illuminator is now available in a surface-mountable package. The
SMAL illuminator is assembled with a total of 60 high efficiency diode chips, mounted
on an AlN ceramics plate, and covered with clear silicone resin. This extremely
high output power illuminator is designed for high current operation with proper
heat sinking to improve thermal conductivity. Most standard IR and NIR wavelengths
are offered in the SMAL line.
Please contact us for more information.
|
New Product -- UV LED Array
|
 |
UV LED Array P390-7722B is designed for UV LED illuminating
high power source. It is composed of 1mm * 1mm high power UV
die by 24pcs mounted on copper substrate as direct bonding with
silver plated reflector and is covered by silicone resin. Total
power is 4.5W at 390nm. >> learn
more ...
|
New Product -- High Powered Illuminator
|
 |
High Powered Illuminator now available with heat sink and +/- 13 degree lens. Our
illuminators consist of 60 chips mounted on a metal stem TO-66 package with AlN
ceramics and covered with clear silicone and epoxy resin. These illuminators are
designed to be used with proper heat sinking to improve thermal conductive efficiency.
>> learn more....
|
New Product -- Superbeam LEDs
|
 |
These high power LEDs consist of a 800 micron
die mounted on specially designed 4 pin lead frame which allows
the LED to be operated at a pulsed current of 4 A under 4.5V for
a stable long life. We can package any standard visible and IR
wavelength into this FL package. Please check out the Superbeam
LED page or contact us for
more information. |
|
